Culture plate for
measuring the resorption ability of osteoclasts |
 |
| |
|
|
 |
| |
|
|
|
|
SEM picture |
SEM picture ( x3,500 )
|
|
Ca-P thin film-coated
surface |
arrow
head: resorption pit /arrow:
osteoclast |
| |
|
> Description
|
|
|
Osteoclast is
a
large
multinucleate cell formed from differentiated
macrophage, responsible for breakdown of bone. It could
be characterized by the multi-nucleation, TRAP positive
and formation of resorption pit. |
|
|
OAAS™is
a culture plate to measure the activity of the
osteoclast in bone research. Due to its bottom coated
with low crystalline of carbonated calcium phosphate,
OAAS™ resembles human bone and will be a perfect
substitute for dentin slice ever.
|
|
| |
|
|
|
  |
|
Activities
can be observed with bare eyes during cultivations
|
|
|
|
|
You will have reliable data because
the OAAS™ wells are bottom coated with calcium phosphate
which acts as a substrate for the osteoclast, and it is
more comparable to human bone than other products coated
with synthetic hydroxyapatite' |
|
|
You can observe the differentiation
while you culture the osteoclast precursor cells.
(Culture period: 2-3 days for matured osteoclast, 7-12
days for precursor cell) |
|
|
You can observe the resorption area
under light microscope without SEM and even with your
bare eyes during culture due to the clear calcium
carbonate coated wells. |
|
|
|
|
|
>
Specification
|
|
Category
|
Description |
|
Product type |
Culture Plate |
|
Growth surface |
Useful for tissue culture |
|
Coating type |
Low crystalline of carbonated calcium phosphate
|
|
Lid
|
Yes |
|
Shape
|
Flat-bottom
|
|
Size
|
4well, 24well, 48well |
|
Volume
|
OAAS-4
|
4well
|
2ml
|
|
OAAS-24
|
24well
|
2ml
|
|
OAAS-48
|
48well
|
1ml
|
|
Growth Area |
OAAS-4
|
4well
|
1.9cm2
|
|
OAAS-24 |
24well
|
1.9cm2
|
|
OAAS-48
|
48well |
1cm2
|
|
Material |
White with clear bottom |
|
Trademark |
OAAS
|
|
Special Order |
Special
order such as trace elements incorporated,
different crystallinity, variable thickness,
specific protein bound, 96-well plate, or
chamber slide / cover slips, may be accepted.
Please contact us for further information. |
|
|
|
|
